Marine Butterfly Valves

A range of marine butterfly valves particularly suited for marine applications such as ballast systems, oil cargo pumping systems and ship side duties. They have type approvals by Lloyds, DNV, B.V, RINA, ABS, GL, and on request 3.1 and 3.2 certificates are available on selected valves. We can also offer a range of manual, pneumatic, electric and hydraulic actuators to suit.

JV100006 – Aluminium Bronze Wafer Butterfly Valve, NBR Lined

A butterfly valve with an ali-bronze body and disc and NBR liner suitable for a wide variety of isolation duties particularly marine applications. Manually operated, supplied with a lockable lever or gearbox.

Type
Multi-Flange Wafer
Size & Connections
DN50 to D300 • Wafer – Between BS4504 PN6/10/16 & ANSI150 Flanges
Duty
Air • Inert Gas • Oil • Seawater • Water
Materials
Aluminium Bronze Body & Disc • NBR Liner
Pressure Rating
PN16
Temperature
-10°C to 120°C
Compliance & Approvals
DNV-GL & BV Type Approval • Length to EN558-1 Series 20 • ISO 5211 Top Mounting
Contact UsJV100006 – Aluminium Bronze Wafer Butterfly Valve, NBR Lined & Aluminium Bronze Disc - PDF DatasheetISO5211 Pad MountDNV Germanischer Lloyd Type ApprovedBureau Veritas Type Approved

JV100006 – Aluminium Bronze Wafer Butterfly Valve, NBR Lined & Aluminium Bronze Disc

JV57N – Marine Ductile Iron Wafer Butterfly Valve, NBR Lined

Marine quality butterfly valve with a bonded NBR liner suitable for many duties including oils and hydrocarbons.  Supplied bare shaft, please specify if lever, gearbox or actuator is required.

Type
Multi-Flange Wafer
Size & Connections
DN40 to DN1200 • Wafer – Between BS4504 PN6/10/16/25, ANSI150 & JIS 5K Flanges*
Duty
Air • Inert Gas • Oil • Seawater • Water
Materials
Ductile Iron Body • Stainless Steel or Ali-Bronze Disc* • NBR Liner
Pressure Rating
50-200mm PN16 • 250-1200mm PN10
Temperature
0°C to 80°C
Compliance & Approvals
Lloyds, DNV, ABS, BV Type Approval • 3.1 & 3.2 Cert (on request) • EN558-1 Series 20
* Specify when enquiring
Contact UsJV57N – Marine Ductile Iron Wafer Butterfly Valve, NBR Lined - PDF DatasheetISO5211 Pad Mount3.1 & 3.1 Material Certification (on request)

JV57N – Marine Ductile Iron Wafer Butterfly Valve, NBR Lined

JV57E – Marine Ductile Iron Wafer Butterfly Valve, EPDM Lined

Marine quality butterfly valve with a bonded EPDM liner suitable for many duties including water.  Supplied bare shaft, please specify if lever, gearbox or actuator is required.

Type
Multi-Flange Wafer
Size & Connections
DN40 to DN1200 • Wafer – Between BS4504 PN6/10/16/25, ANSI150 & JIS 5K Flanges*
Duty
Seawater • Water
Materials
Ductile Iron Body • Ali-Bronze or Stainless Steel Disc* • EPDM Liner
Pressure Rating
50-200mm PN16 • 250-1200mm PN10
Temperature
-30°C to 110°C
Compliance & Approvals
Lloyds, DNV, ABS, BV Type Approval • 3.1 & 3.2 Cert (on request) • EN558-1 Series 20
* Specify when enquiring
Contact UsJV57E – Marine Ductile Iron Wafer Butterfly Valve, EPDM Lined - PDF DatasheetISO5211 Pad Mount3.1 & 3.1 Material Certification (on request)

JV57E – Marine Ductile Iron Wafer Butterfly Valve, EPDM Lined

JV57V – Marine Ductile Iron Wafer Butterfly Valve, Viton Lined

Marine quality butterfly valve with a bonded Viton liner suitable for many high-temperature duties.  Supplied bare shaft, please specify if lever, gearbox or actuator is required.

Type
Multi-Flange Wafer
Size & Connections
DN40 to DN1200 • Wafer – Between BS4504 PN6/10/16/25, ANSI150 & JIS 5K Flanges*
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Ductile Iron Body • Stainless Steel or Ali-Bronze Disc* • Viton Liner
Pressure Rating
50-200mm PN16 • 250-1200mm PN10
Temperature
0°C to 200°C
Compliance & Approvals
Lloyds, DNV, ABS, BV Type Approval • 3.1 & 3.2 Cert (on request) • EN558-1 Series 20
* Specify when enquiring
Contact UsJV57V – Marine Ductile Iron Wafer Butterfly Valve, Viton Lined - PDF DatasheetISO5211 Pad Mount3.1 & 3.1 Material Certification (on request)

JV57V – Marine Ductile Iron Wafer Butterfly Valve, Viton Lined

JV64N – Marine Ductile Iron Lugged & Tapped Butterfly Valve, NBR Lined

Marine quality butterfly valve with a bonded NBR liner suitable for many duties including oils and hydrocarbons.  Supplied bare shaft, please specify if lever, gearbox or actuator is required.

Type
Lugged & Tapped
Size & Connections
DN40 to DN1200 • BS4504 PN6/10/16, ANSI150 & JIS 5/10K*
Duty
Air • Inert Gas • Oil • Seawater • Water
Materials
Ductile Iron Body • Stainless Steel or Ali-Bronze Disc* • NBR Liner
Pressure Rating
50-200mm PN16 • 250-1200mm PN10
Temperature
0°C to 80°C
Compliance & Approvals
Lloyds, DNV, ABS, BV Type Approval • 3.1 & 3.2 Cert (on request) • EN558-1 Series 20
* Specify when enquiring
Contact UsJV64N – Marine Ductile Iron Lugged Butterfly Valve, NBR Lined - PDF DatasheetISO5211 Pad Mount3.1 & 3.1 Material Certification (on request)

JV64N – Marine Ductile Iron Lugged Butterfly Valve, NBR Lined

JV64E – Marine Ductile Iron Lugged & Tapped Butterfly Valve, EPDM Lined

Marine quality butterfly valve with a bonded EPDM liner suitable for many duties including water.  Supplied bare shaft, please specify if lever, gearbox or actuator is required.

Type
Lugged & Tapped
Size & Connections
DN40 to DN1200 • BS4504 PN6/10/16, ANSI150 & JIS 5/10K*
Duty
Seawater • Water
Materials
Ductile Iron Body • Ali-Bronze or Stainless Steel Disc* • EPDM Liner
Pressure Rating
50-200mm PN16 • 250-1200mm PN10
Temperature
-30°C to 110°C
Compliance & Approvals
Lloyds, DNV, ABS, BV Type Approval • 3.1 & 3.2 Cert (on request) • EN558-1 Series 20
* Specify when enquiring
Contact UsJV64E – Marine Ductile Iron Lugged Butterfly Valve, EPDM Lined - PDF DatasheetISO5211 Pad Mount3.1 & 3.1 Material Certification (on request)

JV64E – Marine Ductile Iron Lugged Butterfly Valve, EPDM Lined



JV64V – Marine Ductile Iron Lugged & Tapped Butterfly Valve, Viton Lined

Marine quality butterfly valve with a bonded Viton liner suitable for many high-temperature duties.  Supplied bare shaft, please specify if lever, gearbox or actuator is required.

Type
Lugged & Tapped
Size & Connections
DN40 to DN1200 • BS4504 PN6/10/16, ANSI150 & JIS 5/10K*
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Ductile Iron Body • Stainless Steel or Ali-Bronze Disc* • Viton Liner
Pressure Rating
50-200mm PN16 • 250-1200mm PN10
Temperature
0°C to 200°C
Compliance & Approvals
Lloyds, DNV, ABS, BV Type Approval • 3.1 & 3.2 Cert (on request) • EN558-1 Series 20
* Specify when enquiring
Contact UsJV64V – Marine Ductile Iron Lugged Butterfly Valve, Viton Lined- PDF DatasheetISO5211 Pad Mount3.1 & 3.1 Material Certification (on request)

JV64V – Marine Ductile Iron Lugged Butterfly Valve, Viton Lined

JV36N – Marine Ductile Iron Double Flange Butterfly Valve, NBR Lined – JIS F7480 Length

Marine quality butterfly valve with a bonded NBR liner suitable for many duties including oils and hydrocarbons.  Supplied bare shaft, please specify if lever, gearbox or actuator is required.

Type
Double Flanged
Size & Connections
DN40 to DN600 • BS4504 PN6/10/16, ANSI150 & JIS 5/10K*
Duty
Air • Inert Gas • Oil • Seawater • Water
Materials
Ductile Iron Body • Stainless Steel or Ali-Bronze Disc* • NBR Liner
Pressure Rating
50-200mm PN16 • 250-1200mm PN10
Temperature
0°C to 80°C
Compliance & Approvals
Lloyds, DNV, ABS, BV Type Approval • 3.1 & 3.2 Cert (on request) • JIS F7480
* Specify when enquiring
Contact UsJV36N – Marine Ductile Iron Double Flange Butterfly Valve, NBR Lined - JIS F7480 Length - PDF DatasheetISO5211 Pad Mount3.1 & 3.1 Material Certification (on request)

JV36N – Marine Ductile Iron Double Flange Butterfly Valve, NBR Lined - JIS F7480 Length

JV36E – Marine Ductile Iron Double Flange Butterfly Valve, EPDM Lined – JIS F7480 Length

Marine quality butterfly valve with a bonded EPDM liner suitable for many duties including water.  Supplied bare shaft, please specify if lever, gearbox or actuator is required.

Type
Double Flanged
Size & Connections
DN40 to DN600 • BS4504 PN6/10/16, ANSI150 & JIS 5/10K*
Duty
Seawater • Water
Materials
Ductile Iron Body • Ali-Bronze or Stainless Steel Disc* • EPDM Liner
Pressure Rating
50-200mm PN16 • 250-1200mm PN10
Temperature
-30°C to 110°C
Compliance & Approvals
Lloyds, DNV, ABS, BV Type Approval • 3.1 & 3.2 Cert (on request) • JIS F7480
* Specify when enquiring
Contact UsJV36E – Marine Ductile Iron Double Flange Butterfly Valve, EPDM Lined - JIS F7480 Length - PDF DatasheetISO5211 Pad Mount3.1 & 3.1 Material Certification (on request)

JV36E – Marine Ductile Iron Double Flange Butterfly Valve, EPDM Lined - JIS F7480 Length

JV36V – Marine Ductile Iron Double Flange Butterfly Valve, Viton Lined – JIS F7480 Length

Marine quality butterfly valve with a bonded Viton liner suitable for many high-temperature duties.  Supplied bare shaft, please specify if lever, gearbox or actuator is required.

Type
Double Flanged
Size & Connections
DN40 to DN600 • BS4504 PN6/10/16, ANSI150 & JIS 5/10K*
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Ductile Iron Body • Stainless Steel or Ali-Bronze Disc* • Viton Liner
Pressure Rating
50-200mm PN16 • 250-1200mm PN10
Temperature
0°C to 200°C
Compliance & Approvals
Lloyds, DNV, ABS, BV Type Approval • 3.1 & 3.2 Cert (on request) • JIS F7480
* Specify when enquiring
Contact UsJV36V – Marine Ductile Iron Double Flange Butterfly Valve, Viton Lined - JIS F7480 Length - PDF DatasheetISO5211 Pad Mount3.1 & 3.1 Material Certification (on request)

JV36V – Marine Ductile Iron Double Flange Butterfly Valve, Viton Lined - JIS F7480 Length

JV46N – Marine Ductile Iron Double Flange Butterfly Valve, NBR Lined – EN558-1 Series 13 Length

Marine quality butterfly valve with a bonded NBR liner suitable for many duties including oils and hydrocarbons.  Supplied bare shaft, please specify if lever, gearbox or actuator is required.

Type
Double Flanged
Size & Connections
DN40 to DN1200 • BS4504 PN6/10/16, ANSI150 & JIS 5/10K*
Duty
Air • Inert Gas • Oil • Seawater • Water
Materials
Ductile Iron Body • Stainless Steel or Ali-Bronze Disc* • NBR Liner
Pressure Rating
50-200mm PN16 • 250-1200mm PN10
Temperature
0°C to 80°C
Compliance & Approvals
Lloyds, DNV, ABS, BV Type Approval • 3.1 & 3.2 Cert (on request) • EN558-1 Series 13
* Specify when enquiring
Contact UsJV46N – Marine Ductile Iron Double Flange Butterfly Valve, NBR Lined - EN558-1 Series 13 Length - PDF DatasheetISO5211 Pad Mount3.1 & 3.1 Material Certification (on request)

JV46N – Marine Ductile Iron Double Flange Butterfly Valve, NBR Lined - EN558-1 Series 13 Length

JV46E – Marine Ductile Iron Double Flange Butterfly Valve, EPDM Lined – EN558-1 Series 13 Length

Marine quality butterfly valve with a bonded EPDM liner suitable for many duties including water.  Supplied bare shaft, please specify if lever, gearbox or actuator is required.

Type
Double Flanged
Size & Connections
DN40 to DN1200 • BS4504 PN6/10/16, ANSI150 & JIS 5/10K*
Duty
Seawater • Water
Materials
Ductile Iron Body • Ali-Bronze or Stainless Steel Disc* • EPDM Liner
Pressure Rating
50-200mm PN16 • 250-1200mm PN10
Temperature
-30°C to 110°C
Compliance & Approvals
Lloyds, DNV, ABS, BV Type Approval • 3.1 & 3.2 Cert (on request) • EN558-1 Series 13
* Specify when enquiring
Contact UsJV46E – Marine Ductile Iron Double Flange Butterfly Valve, EPDM Lined - EN558-1 Series 13 Length - PDF DatasheetISO5211 Pad Mount3.1 & 3.1 Material Certification (on request)

JV46E – Marine Ductile Iron Double Flange Butterfly Valve, EPDM Lined - EN558-1 Series 13 Length

JV46V – Marine Ductile Iron Double Flange Butterfly Valve, Viton Lined – EN558-1 Series 13 Length

Marine quality butterfly valve with a bonded Viton liner suitable for many high-temperature duties.  Supplied bare shaft, please specify if lever, gearbox or actuator is required.

Type
Double Flanged
Size & Connections
DN40 to DN1200 • BS4504 PN6/10/16, ANSI150 & JIS 5/10K*
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Ductile Iron Body • Stainless Steel or Ali-Bronze Disc* • Viton Liner
Pressure Rating
50-200mm PN16 • 250-1200mm PN10
Temperature
0°C to 200°C
Compliance & Approvals
Lloyds, DNV, ABS, BV Type Approval • 3.1 & 3.2 Cert (on request) • EN558-1 Series 13
* Specify when enquiring
Contact UsJV46V – Marine Ductile Iron Double Flange Butterfly Valve, Viton Lined - EN558-1 Series 13 Length - PDF DatasheetISO5211 Pad Mount3.1 & 3.1 Material Certification (on request)

JV46V – Marine Ductile Iron Double Flange Butterfly Valve, Viton Lined - EN558-1 Series 13 Length

JV60N – Marine Ductile Iron Mono Flange Butterfly Valve, NBR Lined

Marine quality butterfly valve with a bonded NBR liner suitable for many duties including oils and hydrocarbons.  Supplied bare shaft, please specify if lever, gearbox or actuator is required.

Type
Mono Flanged
Size & Connections
DN40 to DN1200 • BS4504 PN6/10/16, ANSI150 & JIS 5/10K*
Duty
Air • Inert Gas • Oil • Seawater • Water
Materials
Ductile Iron Body • Stainless Steel or Ali-Bronze Disc* • NBR Liner
Pressure Rating
50-200mm PN16 • 250-1200mm PN10
Temperature
0°C to 80°C
Compliance & Approvals
Lloyds, DNV, ABS, BV Type Approval • 3.1 & 3.2 Cert (on request) • EN558-1 Series 20
* Specify when enquiring
Contact UsJV60N – Marine Ductile Iron Mono Flange Butterfly Valve, NBR Lined - PDF DatasheetISO5211 Pad Mount3.1 & 3.1 Material Certification (on request)

JV60N – Marine Ductile Iron Mono Flange Butterfly Valve, NBR Lined

JV60E – Marine Ductile Iron Mono Flange Butterfly Valve, EPDM Lined

Marine quality butterfly valve with a bonded EPDM liner suitable for many duties including water.  Supplied bare shaft, please specify if lever, gearbox or actuator is required.

Type
Mono Flanged
Size & Connections
DN40 to DN1200 • BS4504 PN6/10/16, ANSI150 & JIS 5/10K*
Duty
Seawater • Water
Materials
Ductile Iron Body • Ali-Bronze or Stainless Steel Disc* • EPDM Liner
Pressure Rating
50-200mm PN16 • 250-1200mm PN10
Temperature
-30°C to 110°C
Compliance & Approvals
Lloyds, DNV, ABS, BV Type Approval • 3.1 & 3.2 Cert (on request) • EN558-1 Series 20
* Specify when enquiring
Contact UsJV60E – Marine Ductile Iron Mono Flange Butterfly Valve, EPDM Lined - PDF DatasheetISO5211 Pad Mount3.1 & 3.1 Material Certification (on request)

JV60E – Marine Ductile Iron Mono Flange Butterfly Valve, EPDM Lined

JV60V – Marine Ductile Iron Mono Flange Butterfly Valve, Viton Lined

Marine quality butterfly valve with a bonded Viton liner suitable for many high-temperature duties.  Supplied bare shaft, please specify if lever, gearbox or actuator is required.

Type
Mono Flanged
Size & Connections
DN40 to DN1200 • BS4504 PN6/10/16, ANSI150 & JIS 5/10K*
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Ductile Iron Body • Stainless Steel or Ali-Bronze Disc* • Viton Liner
Pressure Rating
50-200mm PN16 • 250-1200mm PN10
Temperature
0°C to 200°C
Compliance & Approvals
Lloyds, DNV, ABS, BV Type Approval • 3.1 & 3.2 Cert (on request) • EN558-1 Series 20
* Specify when enquiring
Contact UsJV60V – Marine Ductile Iron Mono Flange Butterfly Valve, Viton Lined - PDF DatasheetISO5211 Pad Mount3.1 & 3.1 Material Certification (on request)

JV60V – Marine Ductile Iron Mono Flange Butterfly Valve, Viton Lined
