JV151005 – Stainless Steel Strainer

The JV151015 stainless steel Y-type strainer is ideally suited for the protection of meters, pumps, valves and other pipeline equipment in a wide range of applications including chemical & petrochemical industries.

Type
Y-Type
Size & Connections
10mm (3/8″) to 100mm (4″) • BSP
Duty
Air • Inert Gases • Oil • Process • Steam • Water
Materials
Stainless Steel Body • Stainless Steel Filter Screen
Pressure Rating
16 bar (10 bar:- 65mm-100mm)
Temperature
-10°C to 110°C
Compliance & Approvals
3.1 Material Certificate (on request)
Contact UsJV151005 – Stainless Steel Y-Type Strainer - PDF Datasheet

JV151005 – Stainless Steel Y-Type Strainer

12B – Spirax Sarco Bronze Strainer

This Y-type strainer is of high-quality construction and is suitable for many applications including water, steam and oil. It is supplied as standard, with a stainless steel 0.8mm perforation screen. A choice of various perforated and woven mesh screens are available in both stainless steel and monel metal.

Type
Y-Type
Size & Connections
15mm (1/2″) to 80mm (3″) • BSP
Duty
Air • Inert Gases • Oil • Process • Steam • Water
Materials
Bronze Body • Stainless Steel Filter Screen (Monel option)
Pressure Rating
PN25
Temperature
-10°C to 260°C (dependent on pressure)
Compliance & Approvals
3.1 Material Certificate (on request)
Contact Us12B – Spirax Sarco Bronze Y-Type Strainer - PDF DatasheetSpirax Sarco

12B – Spirax Sarco Bronze Y-Type Strainer

12S – Spirax Sarco SG Iron Strainer

This Y-type strainer is of high-quality construction and is suitable for many applications including water, steam and oil. It is supplied as standard, with a stainless steel 0.8mm perforation screen. A choice of various perforated and woven mesh screens are available in both stainless steel and monel metal.

Type
Y-Type
Size & Connections
15mm (1/2″) to 80mm (3″) • BSP
Duty
Air • Inert Gases • Oil • Process • Steam • Water
Materials
SG Iron Body • Stainless Steel Filter Screen (Monel option)
Pressure Rating
PN25
Temperature
-10°C to 260°C (dependent on pressure & size)
Compliance & Approvals
3.1 Material Certificate (on request)
Contact Us12S – Spirax Sarco SG Iron Y-Type Strainer - PDF DatasheetSpirax Sarco

12S – Spirax Sarco SG Iron Y-Type Strainer

JV150003 – Cast Iron Flanged Strainer

The JV150003 is an economical cast iron Y type strainer with a stainless steel screen, ideally suited for water applications to protect meters, pumps, valves and other pipeline equipment.

Type
Y-Type
Size & Connections
DN15 to DN400 • PN16 Flange (others on request)
Duty
Air • Inert Gases • Oil • Process • Steam • Water
Materials
Cast Iron Body • Stainless Steel Filter Screen
Pressure Rating
16 Bar
Temperature
-10°C to 180°C @ 16 Bar • 300°C @ 9.6 Bar

Contact UsJV150003 – Cast Iron Flanged Y-Type Strainer - PDF Datasheet

JV150003 – Cast Iron Flanged Y-Type Strainer

JV150004 – Cast Steel Flanged Strainer – PN16

The JV150004 cast steel Y type strainer with a stainless steel screen is suitable for many applications to protect meters, pumps, valves and other pipeline equipment.

Type
Y-Type
Size & Connections
DN15 to DN150 • PN25/40 Flange
Duty
Air • Inert Gases • Oil • Process • Steam • Water
Materials
Cast Steel Body • Stainless Steel Filter Screen
Pressure Rating
16 Bar
Temperature
-10°C to 50°C @ 40 Bar • -20°C @ 30 Bar • 400°C @ 30 Bar
Contact UsJV150004 – Cast Steel Flanged Strainer - PDF Datasheet

JV150004 – Cast Steel Flanged Strainer

JV150005 – Stainless Steel Flanged Strainer – PN16

The JV150005 stainless steel ‘Y’ type strainer with a stainless steel screen ideally suited for use in the water distribution, gas oil, steam and petrochemical applications to protect meters, pumps, valves and other pipeline equipment.

Type
Y-Type
Size & Connections
DN25 to DN300 • PN16 Flange
Duty
Air • Inert Gases • Oil • Process • Steam • Water
Materials
Stainless Steel Body • Stainless Steel Filter Screen
Pressure Rating
16 Bar
Temperature
-20°C to 450°C (dependent on pressure)
Contact UsJV150005 – Stainless Steel Flanged Strainer - PN16 - PDF Datasheet

JV150005 – Stainless Steel Flanged Strainer - PN16

JV151004 – Carbon Steel Flanged Strainer – ANSI 150

The JV151004 carbon steel ‘Y’ type strainer with a stainless steel screen ideally suited for use in the water distribution, gas oil, steam and petrochemical applications to protect meters, pumps, valves and other pipeline equipment.

Type
Y-Type
Size & Connections
DN50 to DN400 • ASA 150 Flange
Duty
Air • Inert Gases • Oil • Process • Steam • Water
Materials
Carbon Steel Body • Stainless Steel Filter Screen
Pressure Rating
20 Bar
Temperature
-29°C to 425°C (dependent on pressure)
Compliance & Approvals
Length to ASME B16.10 Table 1 & EN 558 series 10 (series 7 for DN150)
Contact UsJV151004 – Carbon Steel Flanged Strainer - ANSI 150 - PDF Datasheet

JV151004 – Carbon Steel Flanged Strainer - ANSI 150

JV150007 – Carbon Steel Flanged Strainer – ANSI 300

The JV150007 carbon steel ‘Y’ type strainer with a stainless steel screen ideally suited for use in the water distribution, gas oil, steam and petrochemical applications to protect meters, pumps, valves and other pipeline equipment.

Type
Y-Type
Size & Connections
DN50 to DN400 • ASA 300 Flange
Duty
Air • Inert Gases • Oil • Process • Steam • Water
Materials
Carbon Steel Body • Stainless Steel Filter Screen
Pressure Rating
50 Bar
Temperature
-29°C to 425°C (dependent on pressure)
Compliance & Approvals
Length to ASME B16.10 Table 2 Series 15 (DN50-300) Series 17 (DN350-400)
Contact UsJV150007 – Carbon Steel Flanged Strainer - ANSI 300 - PDF Datasheet

JV150007 – Carbon Steel Flanged Strainer - ANSI 300

JV150006 – Stainless Steel Flanged Strainer – ANSI 150

The JV150006 stainless steel ‘Y’ type strainer with a stainless steel screen ideally suited for use in the water distribution, gas oil, steam and petrochemical applications to protect meters, pumps, valves and other pipeline equipment.

Type
Y-Type
Size & Connections
DN25 to DN300 • PN16 Flange
Duty
Air • Inert Gases • Oil • Process • Steam • Water
Materials
Stainless Steel Body • Stainless Steel Filter Screen
Pressure Rating
Class 150
Temperature
-20°C to 450°C (dependent on pressure)
Contact UsJV150006 – Stainless Steel Flanged Strainer - ANSI 150 - PDF Datasheet

JV150006 – Stainless Steel Flanged Strainer - ANSI 150

JV150022 – Cast Iron WRAS Approved Y-Type Strainer

The JV150022 is an economical WRAS approved cast iron Y type strainer with a stainless steel screen, ideally suited for potable water applications to protect meters, pumps, valves and other pipeline equipment.

Type
Y Pattern
Size & Connections
DN50 to DN300 • PN16 Flange
Duty
Water
Materials
Cast Iron (Epoxy Coated) Body • Stainless Steel Filter Screen
Pressure Rating
16 Bar
Temperature
-10°C to 120°C
Compliance & Approvals
WRAS
Contact UsJV150022 – Cast Iron WRAS Approved Y-Type Strainer - PDF DatasheetWRAS Approved Product

JV150022 – Cast Iron WRAS Approved Y-Type Strainer

JV150020 – Cast Iron Y-Type Strainer – Flanged PN6

An economical cast iron Y-type strainer with a stainless steel screen ideally suited for water applications to protect meters, pumps, valves and other pipeline equipment.

Type
Y-Type
Size & Connections
DN50 to DN200 • PN6 Flange
Duty
Air • Inert Gas • Oil • Water
Materials
Cast Iron Body & Bonnet • Stainless Steel Filter Screen
Pressure Rating
16 Bar
Temperature
-10 to 150°C
Contact UsJV150020 – Cast Iron Y-Type Strainer - Flanged PN6 - PDF Datasheet

JV150021 – Cast Iron Y-Type Strainer - Flanged PN6

JV150021 – Carbon Steel Class 800 Y-Type Strainer

The JV150021 carbon steel class 800 Y-type strainer is designed to API 602 and tested to API 598, it is suitable for high pressure and temperature duties. This valve can be supplied with BSPT, NPT threaded or socket weld ends.

Type
Y-Type
Size & Connections
15mm (1/2″) to 50mm (2″) BSP Female (NPT & Socket Weld on request)
Duty
Air • Inert Gas • Oil • Process • Steam • Water
Materials
Carbon Steel Body & Bonnet • Stainless Steel Filter Screen
Pressure Rating
Class 800
Temperature
-29 to 425°C (depending on pressure)
Compliance & Approvals
Class 800 • Designed to API 602 • Tested to API 598
Contact UsJV150021 – Carbon Steel Class 800 Y-Type Strainer - PDF Datasheet

JV150021 – Carbon Steel Class 800 Y-Type Strainer
