Screw Down Non-Return (SDNR) Globe Valves

Screw down non-return globe valves also known as SDNR globe valves are used to prevent reverse flow when in the open position and for providing a leak-tight shut off with the capability of being used partially open to regulate flow.

JV070002 – Bronze SDNR Globe Valve

Globe valve with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty. Manually operated, supplied with a handwheel.

Type
Screw Down Non-Return • Screwed Bonnet • Rising Stem
Size & Connections
15mm (1/2″) to 50mm (2″) BSPP Female
Duty
Air •Inert Gas • Oil • Steam • Water
Materials
Bronze Body • Brass Bonnet & Stem • PTFE Disc
Pressure Rating
PN25
Temperature
-20 to 198°C
Buy JV070002 - Globe ValveJV070002 - Globe Valve - PDF Datasheet

JV070002 - Bronze SDNR Globe Valve

JV071005 – Bronze Union Bonnet SDNR Marine Globe Valve

Secured union bonnet globe valve with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duties. Class society inspection and 3.1 material certification can be arranged on request.

Type
Screw Down Non-Return (SDNR) • Secured Union Bonnet • Rising Stem
Size & Connections
6mm (1/4″) to 80mm (3″) BSP Female
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Bronze Body & Bonnet : Brass Stem (Bronze on request) • Bronze Disc
Pressure Rating
PN16
Temperature
120°C @ 16 Bar • 195°C @ 10 Bar
Compliance & Approvals
3.1 & 3.2 Material Certification (available on request)
Contact UsJV071005 - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

JV071005 - Bronze Union Bonnet SDNR Marine Globe Valve

JV071003 – Bronze Union Bonnet SDNR Marine Angle Globe Valve

Secured union bonnet angled globe valve with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duties. Class society inspection and 3.1 material certification can be arranged on request.

Type
Screw Down Non-Return (SDNR) • Secured Union Bonnet • Rising Stem : Angle
Size & Connections
6mm (1/4″) to 80mm (3″) BSP Female
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Bronze Body & Bonnet • Brass Stem (Bronze on request) • Bronze Disc
Pressure Rating
PN16
Temperature
120°C @ 16 Bar • 195°C @ 10 Bar
Compliance & Approvals
3.1 & 3.2 Material Certification (available on request)
Contact UsJV071003 - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

JV071003 - Bronze Union Bonnet SDNR Angle Marine Globe Valve

JV070009 – Bronze SDNR Globe Valve

Globe valve with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty.

Type
Screw Down Non-Return • Screwed Bonnet • Rising Stem
Size & Connections
DN15 to DN100 • PN16 Flange (others on request)
Duty
Air • Inert Gas • Oil • Steam • Water
Materials
Bronze Body & Bonnet • Brass Stem • PTFE Disc
Pressure Rating
PN16
Temperature
-10 to 180°C
Contact UsJV070009 - Globe Valve - PDF Datasheet

JV070009 - Bronze SDNR Globe Valve

JV070042 – Bronze Marine Union Bonnet SDNR Globe Valve

Secured union bonnet globe valve with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty. Class society inspection and 3.1 material certification can be arranged on request.

Type
Screw Down Non-Return (SDNR) • Secure Union Bonnet • Rising Stem
Size & Connections
DN10 to DN100 • PN16 Flange (others on request)
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Bronze Body & Bonnet • Brass Stem (Phosphor Bronze on request) • Bronze Disc
Pressure Rating
PN16
Temperature
120°C @ 16 Bar • 180°C @ 10 Bar
Compliance & Approvals
3.1 & 3.2 Material Certification (available on request)
Contact UsJV070042 - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

JV070042 - Bronze Marine Union Bonnet SDNR Globe Valve Flanged PN16

JV070044 – Bronze Marine Union Bonnet SDNR Angle Globe Valve

Secured union bonnet globe valve with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty. Class society inspection and 3.1 material certification can be arranged on request.

Type
Screw Down Non-Return (SDNR) • Secure Union Bonnet • Rising Stem • Angle
Size & Connections
DN10 to DN80 • PN16 Flange (others on request)
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Bronze Body & Bonnet • Brass Stem (Phosphor Bronze on request) • Bronze Disc
Pressure Rating
PN16
Temperature
120°C @ 16 Bar • 180°C @ 10 Bar
Compliance & Approvals
3.1 & 3.2 Material Certification (available on request)
Contact UsJV070044 - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

JV070044 - Bronze Marine Union Bonnet SDNR Angle Globe Valve Flanged PN16

133 – Bronze Marine Globe Valve

Quality globe valve with open & shut indicator suitable for marine applications. Lloyds, B.V., DNV, Germanischer Lloyds Inspection and 3.1 material certification can be arranged on request.

Type
Screw Lift (SDNR on request) • Bolted Bonnet • Rising Stem • O/S Indicator
Size & Connections
DN15 to DN100 • PN16 Flange (others on request)
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Bronze Body & Bonnet • Manganese Bronze Stem • Bronze Disc (St. Steel on request)
Pressure Rating
PN16
Temperature
Contact sales for details
Compliance & Approvals
3.1 & 3.2 Material Certification (available on request)
Contact Us133 - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

133 - Bronze Marine Globe Valve Flanged PN16

133L – Bronze Marine Angle Globe Valve

Quality angled globe valve with open & shut indicator suitable for marine applications. Lloyds, B.V., DNV, Germanischer Lloyds Inspection and 3.1 material certification can be arranged on request.

Type
Screw Lift (SDNR on request) • Bolted Bonnet • Rising Stem • O/S Indicator • Angle
Size & Connections
DN15 to DN100 • PN16 Flange (others on request)
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Bronze Body & Bonnet • Manganese Bronze Stem • Bronze Disc (St. Steel on request)
Pressure Rating
PN16
Temperature
Contact sales for details
Compliance & Approvals
3.1 & 3.2 Material Certification (available on request)
Contact Us133L - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

133L - Bronze Marine Angle Globe Valve Flanged PN16

233 SDNR – Bronze Marine SDNR Globe Valve to DIN 86261

Marine globe valve with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty. Class society inspection and 3.1 material certification can be arranged on request.

Type
Screw Down Non-Return (SDNR) • Bolted Bonnet • Rising Stem • O/S Indicator
Size & Connections
DN15 to DN500 • PN16/10 Flange (others on request)
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Bronze Body & Bonnet • Brass Stem (Phosphor Bronze on request) • Bronze Disc
Pressure Rating
Temperature
Up to 180°C (dependent on pressure & size)
Compliance & Approvals
DIN 86261 • 3.1 & 3.2 Material Certification (available on request)
Contact Us233 SDNR - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

233 SDNR - Bronze Marine SDNR Globe Valve to DIN86261 Flanged PN16/10

233L SDNR – Bronze Marine SDNR Angle Globe Valve to DIN 86261

Angle pattern marine globe valve with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty. Class society inspection and 3.1 material certification can be arranged on request.

Type
Screw Down Non-Return (SDNR) • Bolted Bonnet • Rising Stem • O/S Indicator • Angle
Size & Connections
DN15 to DN500 • PN16/10 Flange (others on request)
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Bronze Body & Bonnet • Brass Stem (Phosphor Bronze on request) • Bronze Disc
Pressure Rating
Temperature
Up to 180°C (dependent on pressure & size)
Compliance & Approvals
DIN 86261 • 3.1 & 3.2 Material Certification (available on request)
Contact Us233L SDNR - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

233L SDNR - Bronze Marine Angle Globe Valve to DIN86260 Flanged PN16/10

333 SDNR – Bronze Marine Short Pattern SDNR Globe Valve

Marine globe valve with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty. Class society inspection and 3.1 material certification can be arranged on request.

Type
Screw Down Non-Return (SDNR) • Bolted Bonnet • Rising Stem • O/S Indicator
Size & Connections
DN15 to DN150 • PN16/10 Flange (others on request)
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Bronze Body & Bonnet • Brass Stem (Phosphor Bronze on request) • Bronze Disc
Pressure Rating
Temperature
Up to 180°C (dependent on pressure & size)
Compliance & Approvals
3.1 & 3.2 Material Certification (available on request)
Contact Us333 SDNR - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

333 SDNR - Bronze Marine Short Pattern Globe Valve Flanged PN16/10

333L SDNR – Bronze Marine Short Pattern SDNR Angle Globe Valve

Angle pattern marine globe valve with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty. Class society inspection and 3.1 material certification can be arranged on request.

Type
Screw Down Non-Return (SDNR) • Bolted Bonnet • Rising Stem • O/S Indicator • Angle
Size & Connections
DN15 to DN150 • PN16/10 Flange (others on request)
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Bronze Body & Bonnet • Brass Stem (Phosphor Bronze on request) • Bronze Disc
Pressure Rating
Temperature
Up to 180°C (dependent on pressure & size)
Compliance & Approvals
3.1 & 3.2 Material Certification (available on request)
Contact Us333L SDNR - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

333L SDNR - Bronze Marine Short Pattern Globe Valve Flanged PN16/10

433 SDNR – Bronze Marine 1270-LK Pattern SDNR Globe Valve

Marine globe valve with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty. Class society inspection and 3.1 material certification can be arranged on request.

Type
Screw Down Non-Return (SDNR) • Bolted Bonnet • Rising Stem • O/S Indicator
Size & Connections
DN15 to DN200 • PN16/10 Flange (others on request)
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Bronze Body & Bonnet • Brass Stem (Phosphor Bronze on request) • Bronze Disc
Pressure Rating
Temperature
Up to 180°C (dependent on pressure & size)
Compliance & Approvals
3.1 & 3.2 Material Certification (available on request)
Contact Us433 SDNR - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

433 SDNR - Bronze Marine 1270-LK Pattern Globe Valve Flanged PN16/10

433L SDNR – Bronze Marine 1271-LK Pattern SDNR Angle Globe Valve

Angle pattern marine globe valve with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty. Class society inspection and 3.1 material certification can be arranged on request.

Type
Screw Down Non-Return (SDNR) • Bolted Bonnet • Rising Stem : O/S Indicator • Angle
Size & Connections
DN15 to DN200 • PN16/10 Flange (others on request)
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Bronze Body & Bonnet • Brass Stem (Phosphor Bronze on request) • Bronze Disc
Pressure Rating
Temperature
Up to 180°C (dependent on pressure & size)
Compliance & Approvals
3.1 & 3.2 Material Certification (available on request)
Contact Us433L SDNR - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

433L SDNR - Bronze Marine 1271-LK Pattern Globe Valve Flanged PN16/10

JV070019 – Cast Iron SDNR Globe Valve with Stainless Steel Disc

General purpose cast iron globe valve with a stainless steel disc. Manufactured with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty.

Type
Screw Down Non-Return (SDNR) • Bolted Bonnet • Rising Stem
Size & Connections
DN15 to DN200 • PN16 Flange (others on request)
Duty
Air • Inert Gas • Oil • Steam • Water
Materials
Cast Iron Body & Bonnet • Stainless Steel Stem • Stainless Steel Disc
Pressure Rating
PN16
Temperature
120°C @ 16 Bar • 300°C @ 9.6 Bar
Compliance & Approvals
DIN EN5581 • DIN 3202-1 Series F1
Contact UsJV070019 - Globe Valve - PDF Datasheet

JV070019 - Cast Iron SDNR Globe Valve with Stainless Steel Disc Flanged PN16

JV070049 – Cast Iron SDNR Angle Globe Valve with Stainless Steel Disc

General purpose cast iron SDNR angled globe valve with a stainless steel disc. Manufactured with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty.

Type
Screw Down Non-Return (SDNR) • Bolted Bonnet • Rising Stem • Angle
Size & Connections
DN15 to DN300 • PN16/10 Flange (others on request)
Duty
Air • Inert Gas • Oil • Steam • Water
Materials
Cast Iron Body & Bonnet • Stainless Steel Stem • Stainless Steel Disc
Pressure Rating
PN16
Temperature
120°C @ 16 Bar • 300°C @ 9.6 Bar
Compliance & Approvals
DIN EN5581 • DIN 3202-1 Series F32
Contact UsJV070049 - Globe Valve - PDF Datasheet

JV070049 - Cast Iron SDNR Angle Globe Valve with Stainless Steel Disc Flanged PN16

JV070046 – Cast Iron SDNR Globe Valve with Bronze Disc

General purpose cast iron globe valve with a bronze disc. Manufactured with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty.

Type
Screw Down Non-Return (SDNR) • Bolted Bonnet • Rising Stem
Size & Connections
DN15 to DN200 • PN16 Flange (others on request)
Duty
Air • Inert Gas • Oil • Steam • Water
Materials
Cast Iron Body & Bonnet • High Tensile Brass Stem • Bronze Disc
Pressure Rating
PN16
Temperature
120°C @ 16 Bar • 225°C @ 12 Bar
Compliance & Approvals
DIN EN5581 • DIN 3202-1 Series F1
Contact UsJV070046 - Globe Valve - PDF Datasheet

JV070046 - Cast Iron SDNR Globe Valve with Bronze Disc Flanged PN16/10

JV070050 – Cast Iron SDNR Angle Globe Valve with Bronze Disc

General purpose cast iron SDNR angled globe valve with a bronze disc. Manufactured with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty.

Type
Screw Down Non-Return (SDNR) • Bolted Bonnet • Rising Stem • Angle
Size & Connections
DN15 to DN300 • PN16/10 Flange (others on request)
Duty
Air • Inert Gas • Oil • Steam • Water
Materials
Cast Iron Body & Bonnet • High Tensile Brass Stem • Bronze Disc
Pressure Rating
PN16
Temperature
120°C @ 16 Bar • 225°C @ 12 Bar
Compliance & Approvals
DIN EN5581 • DIN 3202-1 Series F32
Contact UsJV070050 - Globe Valve - PDF Datasheet

JV070050 - Cast Iron SDNR Angle Globe Valve with Bronze Disc Flanged PN16/10

181 – Cast Iron Globe Valve with Bronze Disc to BS EN 13789

General purpose cast iron globe valve with a bronze disc suitable for a wide range of applications.

Type
Screw Lift • Bolted Bonnet • Rising Stem
Size & Connections
DN15 to DN200 • PN16 Flange (others on request)
Duty
Air • Inert Gas • Oil • Water
Materials
Cast Iron Body & Bonnet • High Tensile Brass Stem • Bronze Disc
Pressure Rating
PN16
Temperature
Contact sales for details
Compliance & Approvals
BS EN 13789 (previously BS 5152)
Contact Us181 - Globe Valve - PDF Datasheet

181 - Cast Iron Globe Valve with Bronze Disc to BS EN 13789 Flanged PN16

182 – Cast Iron Angle Globe Valve with Bronze Disc to BS EN 13789

General purpose cast iron angled globe valve with a bronze disc suitable for a wide range of applications.

Type
Screw Lift • Bolted Bonnet • Rising Stem • Angle
Size & Connections
DN15 to DN200 • PN16 Flange (others on request)
Duty
Air • Inert Gas • Oil • Water
Materials
Cast Iron Body & Bonnet • High Tensile Brass Stem • Bronze Disc
Pressure Rating
PN16
Temperature
Contact sales for details
Compliance & Approvals
BS EN 13789 (previously BS 5152)
Contact Us182 - Globe Valve - PDF Datasheet

182 - Cast Iron Angle Globe Valve with Bronze Disc to BS EN 13789 Flanged PN16

JV070052 – Ductile Iron SDNR Globe Valve with Stainless Steel Disc

General purpose ductile iron globe valve with a stainless steel disc. Manufactured with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty. Class society inspection and 3.1 material certification can be arranged on request.

Type
Screw Down Non-Return (SDNR) • Bolted Bonnet • Rising Stem
Size & Connections
DN15 to DN200 • PN16 Flange (others on request)
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Ductile Iron Body & Bonnet • Stainless Steel Stem • Stainless Steel Disc
Pressure Rating
PN16
Temperature
120°C @ 16 Bar • 350°C @ 11 Bar
Compliance & Approvals
DIN EN5581 • DIN 3202-1 Series F1 : 3.1 & 3.2 Material Certs (available on request)
Contact UsJV070052 - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

JV070052 - Ductile Iron SDNR Globe Valve with Stainless Steel Disc Flanged PN16/10

JV070054 – Ductile Iron SDNR Angle Globe Valve with Stainless Steel Disc

General purpose ductile iron SDNR angled globe valve with a stainless steel disc. Manufactured with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty. Class society inspection and 3.1 material certification can be arranged on request.

Type
Screw Down Non-Return (SDNR) • Bolted Bonnet • Rising Stem • Angle
Size & Connections
DN15 to DN300 • PN16/10 Flange (others on request)
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Ductile Iron Body & Bonnet • Stainless Steel Stem • Stainless Steel Disc
Pressure Rating
PN16
Temperature
120°C @ 16 Bar • 350°C @ 11 Bar
Compliance & Approvals
DIN EN5581 • DIN 3202-1 Series F32 • 3.1 & 3.2 Material Certs (available on request)
Contact UsJV070054 - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

JV070054 - Ductile Iron SDNR Angle Globe Valve with Stainless Steel Disc Flanged PN16

JV070056 – Ductile Iron SDNR Globe Valve with Bronze Disc

General purpose ductile iron globe valve with a bronze disc. Manufactured with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty. Class society inspection and 3.1 material certification can be arranged on request.

Type
Screw Down Non-Return (SDNR) • Bolted Bonnet • Rising Stem
Size & Connections
DN15 to DN200 • PN16 Flange (others on request)
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Ductile Iron Body & Bonnet • Special Brass (Som59) Stem • Bronze Disc
Pressure Rating
PN16
Temperature
120°C @ 16 Bar • 225°C @ 14 Bar
Compliance & Approvals
DIN EN5581 • DIN 3202-1 Series F1 • 3.1 & 3.2 Material Certs (available on request)
Contact UsJV070056 - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

JV070056 - Ductile Iron SDNR Globe Valve with Bronze Disc Flanged PN16/10

JV070058 – Ductile Iron SDNR Angle Globe Valve with Bronze Disc

General purpose ductile iron SDNR angled globe valve with a bronze disc. Manufactured with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty. Class society inspection and 3.1 material certification can be arranged on request.

Type
Screw Down Non-Return (SDNR) • Bolted Bonnet • Rising Stem • Angle
Size & Connections
DN15 to DN300 • PN16/10 Flange (others on request)
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Ductile Iron Body & Bonnet • Special Brass (Som59) Stem • Bronze Disc
Pressure Rating
PN16
Temperature
120°C @ 16 Bar • 225°C @ 14 Bar
Compliance & Approvals
DIN EN5581 • DIN 3202-1 Series F32 • 3.1 & 3.2 Material Certs (available on request)
Contact UsJV070058 - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

JV070058 - Ductile Iron SDNR Angle Globe Valve with Bronze Disc Flanged PN16

JV070060 – Cast Steel SDNR Globe Valve with Stainless Steel Disc

Cast steel globe valve with a stainless steel disc suitable for a range of applications including shipside and boiler duties. Manufactured with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty. Class society inspection and 3.1 material certification can be arranged on request.

Type
Screw Down Non-Return (SDNR) • Bolted Bonnet • Rising Stem
Size & Connections
DN15 to DN500 • PN40 Flange (others on request)
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Cast Steel Body & Bonnet • Stainless Steel Stem • Stainless Steel Disc
Pressure Rating
PN40
Temperature
-10°C to 300°C
Compliance & Approvals
DIN EN5581 • DIN 3202-1 Series F1 • 3.1 & 3.2 Material Certs (available on request)
Contact UsJV070060 - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

JV070060 - Cast Steel SDNR Globe Valve with Stainless Steel Disc Flanged PN40

280 – Cast Steel Globe Valve with Stainless Steel Disc to BS 5160

General purpose cast steel globe valve with a stainless steel disc suitable for a wide range of applications.

Type
Screw Lift • Bolted Bonnet • Rising Stem
Size & Connections
DN15 to DN200 • PN40 Flange (others on request)
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Cast Steel Body & Bonnet • Stainless Steel Stem • Stainless Steel Disc
Pressure Rating
PN40
Temperature
Contact sales for details
Compliance & Approvals
BS 5160 • 3.1 & 3.2 Material Certs (available on request)
Contact Us280 - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

280 - Cast Steel Globe Valve with Stainless Steel Disc to BS 5160 Flanged PN40

JV070062 – Cast Steel SDNR Angle Globe Valve with Stainless Steel Disc

Cast steel globe valve with a stainless steel disc suitable for a range of applications including shipside and boiler duties. Manufactured with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty. Class society inspection and 3.1 material certification can be arranged on request.

Type
Screw Down Non-Return (SDNR) • Bolted Bonnet • Rising Stem • Angle
Size & Connections
DN15 to DN500 • PN40 Flange (others on request)
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Cast Steel Body & Bonnet • Stainless Steel Stem • Stainless Steel Disc
Pressure Rating
PN40
Temperature
-10°C to 300°C
Compliance & Approvals
DIN EN5581 • DIN 3202-1 Series F32 • 3.1 & 3.2 Material Certs (available on request)
Contact UsJV070062 - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

JV070062 - Cast Steel SDNR Angle Globe Valve with Stainless Steel Disc Flanged PN40

281 – Cast Steel Angle Globe Valve with Stainless Steel Disc to BS 5160

General purpose cast steel angled globe valve with a stainless steel disc suitable for a wide range of applications.

Type
Screw Lift • Bolted Bonnet • Rising Stem • Angle
Size & Connections
DN15 to DN200 • PN40 Flange (others on request)
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Cast Steel Body & Bonnet • Stainless Steel Stem • Stainless Steel Disc
Pressure Rating
PN40
Temperature
Contact sales for details
Compliance & Approvals
BS 5160 • BS 4312 • 3.1 & 3.2 Material Certs (available on request)
Contact Us281 - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

281 - Cast Steel Angle Globe Valve with Stainless Steel Disc to BS 5160 Flanged PN40

JV070064 – Cast Steel SDNR Globe Valve with Bronze Disc

Cast steel globe valve with a bronze disc suitable for a range of applications including shipside duties. Manufactured with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty. Class society inspection and 3.1 material certification can be arranged on request.

Type
Screw Lift • Bolted Bonnet • Rising Stem
Size & Connections
DN15 to DN300 • PN16/10 Flange (others on request)
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Cast Steel Body & Bonnet • Phosphor Bronze Stem • Bronze Disc
Pressure Rating
PN16
Temperature
Up to 180°C (dependent on pressure & size)
Compliance & Approvals
DIN EN5581 • DIN 3202-1 Series F1 • 3.1 & 3.2 Material Certs (available on request)
Contact UsJV070064 - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

JV070064 - Cast Steel SDNR Globe Valve with Bronze Disc Flanged PN16/10

JV070066 – Cast Steel SDNR Angle Globe Valve with Bronze Disc

Cast steel globe valve with a bronze disc suitable for a range of applications including shipside duties. Manufactured with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty. Class society inspection and 3.1 material certification can be arranged on request.

Type
Screw Lift • Bolted Bonnet • Rising Stem
Size & Connections
DN15 to DN300 • PN16/10 Flange (others on request)
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Cast Steel Body & Bonnet • Phosphor Bronze Stem • Bronze Disc
Pressure Rating
PN16
Temperature
Up to 180°C (dependent on pressure & size)
Compliance & Approvals
DIN EN5581 • DIN 3202-1 Series F1 • 3.1 & 3.2 Material Certs (available on request)
Contact UsJV070066 - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

JV070066 - Cast Steel SDNR Angle Globe Valve with Bronze Disc Flanged PN16/10

F7351 – Bronze JIS Marine SDNR Globe Valve

Bronze metal seated globe valve to JIS Japanese specifications with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty. Class society inspection and 3.1 material certification can be arranged on request.

Type
Screw Down Non-Return • Secured Screwed Bonnet (15-40mm) • Rising Stem
Size & Connections
DN15 to DN65 • JIS-5K Flange
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Bronze Body • Bronze/Brass Bonnet & Stem • Bronze/Brass Disc
Pressure Rating
Up to 7 Bar (dependent on application)
Temperature
Up to 205°C
Compliance & Approvals
JIS-5K • 3.1 & 3.2 Material Certification (available on request)
Contact UsF7351 - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

F7351 - Bronze JIS Marine SDNR Globe Valve Flanged JIS-5K

F7352 – Bronze JIS Marine SDNR Angle Globe Valve

Bronze metal seated angled globe valve to JIS Japanese specifications with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty. Class society inspection and 3.1 material certification can be arranged on request.

Type
Screw Down Non-Return • Secured Screwed Bonnet (15-40mm) : Rising Stem • Angle
Size & Connections
DN15 to DN65 • JIS-5K Flange
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Bronze Body • Bronze/Brass Bonnet & Stem • Bronze/Brass Disc
Pressure Rating
Up to 7 Bar (dependent on application)
Temperature
Up to 205°C
Compliance & Approvals
JIS-5K • 3.1 & 3.2 Material Certification (available on request)
Contact UsF7352 - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

F7352 - Bronze JIS Marine SDNR Angle Globe Valve Flanged JIS-5K

F7409 – Bronze JIS Marine SDNR Globe Valve

Bronze metal seated globe valve to JIS Japanese specifications with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty. Class society inspection and 3.1 material certification can be arranged on request.

Type
Screw Down Non-Return • Secured Screwed Bonnet • Rising Stem
Size & Connections
DN15 to DN40 • JIS-16K Flange
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Bronze Body • Bronze/Brass Bonnet & Stem • Bronze/Brass Disc
Pressure Rating
Up to 22 Bar (dependent on application)
Temperature
Up to 205°C
Compliance & Approvals
JIS-16K • 3.1 & 3.2 Material Certification (available on request)
Contact UsF7409 - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

F7409 - Bronze JIS Marine SDNR Globe Valve Flanged JIS-16K

F7410 – Bronze JIS Marine SDNR Angle Globe Valve

Bronze metal seated angled globe valve to JIS Japanese specifications with a non-return design, preventing reverse flow when in the open position, also suitable for isolation duty. Class society inspection and 3.1 material certification can be arranged on request.

Type
Screw Down Non-Return • Secured Screwed Bonnet • Rising Stem • Angle
Size & Connections
DN15 to DN40 • JIS-16K Flange
Duty
Air • Inert Gas • Oil • Seawater • Steam • Water
Materials
Bronze Body • Bronze/Brass Bonnet & Stem • Bronze/Brass Disc
Pressure Rating
Up to 22 Bar (dependent on application)
Temperature
Up to 205°C
Compliance & Approvals
JIS-16K • 3.1 & 3.2 Material Certification (available on request)
Contact UsF7410 - Globe Valve - PDF Datasheet3.1 & 3.1 Material Certification (on request)

F7410 - Bronze JIS Marine SDNR Angle Globe Valve Flanged JIS-16K
