JV150001 – Strainer

Brass Y-Type Strainer

The JV150001 is an economical brass Y-type strainer with a stainless steel screen is ideally suited for water and general purpose applications.

Size : ¼” (6mm) to 4″ (100mm)

Connection : BSPP

Fluids : Air – Inert Gas – Oil – Water

Screen : Stainless Steel – 0.5mm Perforation

JV150001 Strainer Datasheet

JV150001 Strainer

JV150002 – Strainer

Bronze Y-Type Strainer – Flanged

The JV150002 is an economical bronze Y-type strainer with a stainless steel screen, ideally suited for water and general purpose applications.

Size : ½” (15mm) to 4″ (100mm)

Connection : Flanged – BS4504 PN10/16 (other drillings on request)

Fluids : Air – Inert Gas – Oil – Seawater – Water

Screen : Stainless Steel – 0.5mm, 1.0mm & 1.5mm Perforation

JV150002 Strainer Datasheet

JV150002 Strainer

JV150003 – Strainer

Cast Iron Y-Type Strainer – Flanged

The JV150003 is an economical cast iron Y-type strainer with a stainless steel screen and is ideally suited for water and general purpose applications.

Size : ½” (15mm) to 16″ (400mm)

Connection : Flanged – BS4504 PN10/16 (other drillings on request)

Fluids : Air – Inert Gas – Oil – Water

Screen : Stainless Steel – 1.0mm (15mm-50mm) | 1.25mm (65mm-80mm) | 1.6mm (100mm-400mm)

V150003 Strainer Datasheet

JV150003 - Cast Iron Strainer

JV150004 – Strainer

Cast Steel Y-Type Strainer – Flanged

The JV150004 is an economical cast steel Y type strainer with a stainless steel screen, ideally suited for water applications to protect meters, pumps, valves and other pipeline equipment.

Size : ½” (15mm) to 6″ (150mm)

Connection : Flanged – BS4504 PN25/40 (other drillings on request)

Fluids : Air – Inert Gas – Oil – Steam – Water

Screen : Stainless Steel – 1.0mm (15mm-50mm) | 1.25mm (65mm-80mm) | 1.6mm (100mm-150mm)

JV150004 Strainer Datasheet

JV150004 - Cast Steel Strainer

JV150005 – Strainer

Stainless Steel Y-Type Strainer – Flanged PN16

The JV150005 is a stainless steel Y type strainer with a stainless steel screen suitable for a wide range of applications to protect meters, pumps, valves and other pipeline equipment.

Size : 1″ (25mm) to 12″ (300mm)

Connection : Flanged – BS4504 PN16

Fluids : Air – Inert Gas – Oil – Steam – Water

Screen : Stainless Steel – 1.5mm (25mm) | 2mm (40mm-150mm)

JV150005 Strainer Datasheet

JV150005 - Stainless Steel PN16 Strainer

JV150006 – Stariner

Stainless Steel Y-Type Strainer – Flanged ANSI 150

The JV150006 is a stainless steel Y type strainer with a stainless steel screen suitable for a wide range of applications to protect meters, pumps, valves and other pipeline equipment.

Size : 1″ (25mm) to 6″ (150mm)

Connection : Flanged – ANSI 150

Fluids : Air – Inert Gas – Oil – Steam – Water

Screen : Stainless Steel – 1.5mm (25mm) | 2mm (40mm-150mm)

JV150006 Strainer Datasheet

JV150006 - Stainless Steel ANSI150 Strainer

12B – Strainer

Spirax Sarco Bronze Y-Type Strainer

A high quality strainer with various filter screen perforations, suitable for many applications including water, steam and oil.

Size : ½” (15mm) to 2½” (65mm)

Connection : BSP

Fluids : Air – Inert Gas – Oil – Steam – Water

Screen : Stainless Steel – Various Perforations

12B Strainer Datasheet

12B Strainer

12S – Strainer

Spirax Sarco Iron Y-Type Strainer

A high quality strainer with various filter screen perforations, suitable for many applications including water, steam and oil.

Size : ½” (15mm) to 2″ (50mm)

Connection : BSP

Fluids : Air – Inert Gas – Oil – Steam – Water

Screen : Stainless Steel – Various Perforations

12S Strainer Datasheet

12S Strainer

H4010 – Strainer

Elster WRAS Approved Basket Type Strainer – Flanged

This basket strainer is specifically designed for use with Woltmann type water meters, however it can be used in many other applications.

Size : 1½” (40mm) to 6″ (150mm)

Connection : Flanged – BS4504 PN10/16 (other drillings on request)

Fluids : Air – Inert Gas – Water

Screen : Stainless Steel – 3mm Perforation

H4010 Strainer Datasheet

H4010 Strainer

301101 – Mud Box

Cast Iron Straight Pattern Mud Box (Basket) Strainer

Mud box strainers helps to protect marine systems from damage by filtering debris and large particles in suction and discharge lines for sea cooling and bilge systems.

Size : 25mm to 750mm

Connection : Flanged – BS4504 PN10 (other drillings on request)

Fluids : Sea Water

Screen : Stainless Steel – 4mm Perforation (DN25-65) | 8mm Perforation (DN80-750)

301101 Mudbox Strainer Datasheet

301101 Mud Box Strainer

301102 – Mud Box

Cast Iron Angled Pattern Mud Box (Basket) Strainer

Mud box strainers helps to protect marine systems from damage by filtering debris and large particles in suction and discharge lines for sea cooling and bilge systems.

Size : 25mm to 600mm

Connection : Flanged – BS4504 PN10 (other drillings on request)

Fluids : Sea Water

Screen : Stainless Steel – 4mm Perforation (DN25-65) | 8mm Perforation (DN80-750)

301102 Mudbox Strainer Datasheet

301102 Mud Box Strainer
